GED/eGED and GSD/eGSD Direct Drive Sidewall Propeller Exhaust/Supply Fans

Sidewall Propeller Fan Series New Product

GD Models

Model Features

  • Exhaust air up to 3,500 CFM in high-pressure applications up to 3/4" w.g.
  • 16 gauge galvanized steel panel
  • Formed flanges for added rigidity
  • Integral OSHA approved motor side guard
  • Fabricated aluminum blades, precision pitch
  • Suitable for all angle installation
  • AMCA Air and Sound Licensed
  • cULus 705 Listed
  • Ecowatt® (eGED/eGSD Models ONLY)

AMCA Air and Sound Licensed   cULus Listed   Ecowatt Registered

Model Overview

The GED/eGED and GSD/eGSD Direct Drive Sidewall Propeller Exhaust/Supply Fan features the maximum efficiency, low maintenance and durable, economical operation resulting from the direct drive design. It is available in exhaust configurations to provide general ventilation for a wide variety of buildings and enclosed areas within buildings. Examples include factories, assembly plants, churches, gymnasiums, garages, jails, machine rooms and many others.

They feature extremely quiet operation and an integral motor side guard as standard.

The eGED and eGSD come with our Electronically Commutated (EC) Motor which offers the energy efficiency of a DC motor with the ease of maintenance of DD motors. The motors are 115V, 60 Hz in 1/3 HP & 1/2 HP and is 230V in 3/4 HP. This fully controllable motor offers both reliability and low maintenance in one of the most efficient motor fan combinations in the industry.

JencoFan's eGED/eGSD, motors are the ideal solution for a low cost, fully controlled ventilation system. This motor in the eGED/eGSD can move air volumes up to 4,183 CFM.

5-year fan housing warranty, 1-year motor warranty

GED and GSD Specifications

Size CFM Range Max SP
10 227 to 782 1/4"
12 544 to 1525 1/2"
14 581 to 2546 5/8"
16 889 to 2676 5/8"
18 902 to 2983 5/8"
20 2112 to 3885 1/2"

eGED and eGSD Specifications

Size CFM Range Max SP
12 489 to 1614 1/2"
14 513 to 2205 3/4"
16 584 to 2882 3/4"
18 599 to 4183 3/4"
20 469 to 3718 3/4"
Dimensional Drawing GD
Size A B C D E F
10 16" 10-1/2" 1" 2" 11" 9"
12 16" 12-1/2" 1" 2" 14" 12"
14 20" 14-1/2" 1" 2" 14" 12"
16 20" 16-1/2" 1" 2" 14" 12"
18 24" 18-1/2" 1" 2" 15" 13"
20 24" 20-1/2" 1" 2" 15" 13"

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Disconnect Switches
Extended Lube Lines
Factory Wiring
Filtered Wall Housing Submittal
Gravity Dampers for Exhaust and Supply
Motorized Dampers for Exhaust and Supply
Mounting Angles
Rainhoods/Weatherhoods

Ecowatt® Accessories

ECM Multi-Speed Control IOM

General Catalog Section
Typical Specification Sheet (GED/GSD)
Submittal (GED/GSD)
Submittal (eGED/eGSD)
Instruction and Operation Manual (GED/GSD)
Instruction and Operation Manual (eGED/eGSD)

Description
GED (Exhaust) Revit File
GSD (Supply) Revit File
Exhaust Rainhood (45 degree) Revit File
Supply Rainhood (90 degree) Revit File

  • General/Clean Air
