L2E and L2S Belt Drive Sidewall Propeller Exhaust/Supply Fans

Sidewall Propeller Fan Series

L2 Models

Model Features

  • Exhaust air up to 47,000 CFM in high static pressure applications up to 3/4" w.g.
  • Heavy-gauge galvanized steel panel
  • Die formed galvanized steel blades
  • Sized for minimum 150% of drive horsepower
  • AMCA Air and Sound Licensed
  • cULus 705 Listed

AMCA Air and Sound Licensed   cULus Listed

Model Overview

L2E (exhaust) and L2S (supply) are high capacity wall mounted belt driven propeller fans rated from 5,000 to 47,000 CFM, with static pressure capability up to 3/4" w.g. Their primary application is the exhaust of large volumes of ventilation air from commercial and light industrial buildings such as manufacturing and assembly plants, warehouses, parking garages, gymnasiums, equipment rooms, distribution centers and OEM applications.

Wall mounting provides an easy and economical installation. All necessary accessories are available. Belt driven fans provide large volumes of air at low fan speed and low noise levels and afford quick, easy performance adjustments.

2-year fan housing warranty, 1-year motor warranty

Size CFM Range Max SP
24 2733 to 11273 5/8"
30 4378 to 17109 1/2"
36 2429 to 23846 3/4"
42 3612 to 27472 3/4"
48 7002 to 34010 3/4"
54 10747 to 41715 5/8"
60 15136 to 47161 1/2"
Dimensional Drawing L2
Size A B C D E F Damper O.D. Sq. Flange
24 30" 2" 7-1/2" 1-1/4" 15" 23" 28-1/2"
30 36" 2" 7-1/2" 1-1/4" 15" 24" 34-1/2"
36 42" 2" 7-1/2" 1-1/4" 15" 24" 40-1/2"
42 48" 2" 7-1/2" 1-1/4" 16" 24" 46-1/2"
48 54" 2" 7-1/2" 1-1/4" 16" 24" 52-1/2"
54 60" 2" 7-1/2" 1-1/4" 20" 26" 58-1/2"
60 66" 2" 7-1/2" 1-1/4" 20" 26" 64-1/2"

Mounting Option Description
Wall Housing Heavy-gauge, all galvanized G-90 steel housing provides a simple solution to installing a fan and all required accessories in a rough wall opening. It can be used in exhaust or supply applications and fan sizes 20 to 72 inches.
Filtered Wall Housing For installations where filtering is required. Heavy-gauge, all galvanized G-90 steel filtered wall housings are available in both supply and exhaust configurations. They are available in eight (8) sizes for fans ranging from size 20 to 60 inches. They are designed with the draw-thru concept to achieve the highest filter and fan efficiencies.
Wall Collar Heavy-gauge, all G-90 galvanized mounting collar provides a simple solution to installing a fan in a rough wall opening when a rear safety guard is NOT required.

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Description
Rainhoods/Weatherhoods   Download
Gravity Dampers for Exhaust and Supply   Download
Motorized Dampers for Exhaust and Supply   Download
Center Pivot Motorized   Download
Dampers for Exhaust and Supply   Download
Disconnect Switches   Download
Aluminum Construction   Download
Extended Lube Lines   Download
Mounting Angles   Download
Factory Wiring   Download

Description
L2E and L2S Catalog Pages   Download
L2E and L2S Product Submittal   Download
L2E and L2S Product IOM   Download

  • General/Clean Air
  • Spark Resistant
