STXD, STXDe, and STXDeRHUL Upblast Direct Drive Centrifugal Roof/Sidewall Exhaust Fans

Centrifugal Roof & Wall Fan Series

Centrifugal Roof & Wall Fans
SDBD and SDBDe SDB STXD, STXDe, and STXDeRHUL STXB, STXB-RHUL, and STXB-HP STXB-HT2 and STXB-HT LPD and LPD-SF CWD
STXD, STXDe, and STXDeRHUL Models STXB, STXB-RHUL, and STXB-HP Models

High Wind Tie-Down Kit Option Available

Model Features

  • Exhaust air up to 4,780 CFM in high static pressure applications up to 2-1/4" w.g.
  • Attractive spun aluminum exterior
  • Direct drive units have low sound levels and quiet operation
  • Curved non-overloading backward inclined wheel for efficiency at higher static pressures
  • Roof or sidewall mounting options
  • AMCA Air and Sound Licensed
  • cULus 705 and 762 Listed
  • Ecowatt® (STXDe and STXDeRHUL Models)
  • Miami-Dade NOA and Florida Product Approval Option Available Download letter here.
  • Listed with the Texas Department of Insurance under Product Evaluation RV-126 for wind load and windborne debris resistance per IRC/IBC 2018
  • This product meets the requirements of Buy American (2009) and Build America, Buy America (BABA), as part of IIJA (2022). Download letter here.

AMCA Air and Sound Licensed cULus Listed Ecowatt Registered miami dade noa BABA-ACT

Model Overview

The STXD direct drive fans are designed to exhaust air up to 4,780 CFM, with high static pressure capability up to 2-1/4". The non-overloading backward inclined wheel, with its higher static pressure capability, makes this unit suitable for either ducted or non-ducted applications. Its roof or wall mounting permits short duct runs and more efficient operation. Direct drive units use smaller diameter wheels with lower RPM's, resulting in low sound levels and quiet operation. They have no belts or fan bearings to maintain or adjust and consequently require very little maintenance.

Isolation of the motor from the air stream and the high-velocity air discharge make the STXD ideally suited for the removal of dirty, contaminated and/or high-temperature air from buildings and manufacturing plants. Typical applications include restaurant hoods and similar kitchen exhaust ventilation, fume and smoke removal, laboratory fume hood exhaust and chemical process exhaust.

5-year fan housing warranty, 1-year motor warranty
STXD-RHUL units have 2-year fan housing warranty

Size CFM Range Max SP
6 56 to 308 3/4"
7 78 to 437 3/4"
8 182 to 935 7/8"
10 322 to 1,445 1"
12 470 to 1,918 1-1/4"
14 868 to 3,268 1-1/2"
15 800 to 3,997 2"
16 880 to 4,781 2-1/4"
18 1,098 to 4,272 1-1/4"
Dimensional Drawing

Dimensional data is displayed in inches.

SIZE A B C D ROOF OPENING CURB O.D. DAMPER O.D.
06 18 25-5/16 28-5/8 20-5/16 13-1/2 16-1/2 12
07 18 25-5/16 28-5/8 20-5/16 13-1/2 16-1/2 12
08 18 25-5/16 28-5/8 20-5/16 13-1/2 16-1/2 12
10 18 25-5/16 28-5/8 20-5/16 13-1/2 16-1/2 12
12 20 26-15/16 31-5/16 21-15/16 15-1/2 18-1/2 14
14 20 26-15/16 31-5/16 21-15/16 15-1/2 18-1/2 14
15 24 27-5/8 36-1/2 22-5/8 19-1/2 22-1/2 18
16 24 27-5/8 36-1/2 22-5/8 19-1/2 22-1/2 18
18 30 35-3/4 42-5/8 30-1/2 25-3/16 28-1/2 24

STXD, STXDe, STXDRHUL and STXDeRHUL Kits

Select S-Series (Centrifugal Roof Fans) models are now hurricane and high wind certified for wind-borne debris impact resistance and wind load design pressures up to ±150 PSF.

KIT-PV100X

High Wind Tie-Down Kit

  • Tie-downs
  • Fastened motor cover
Flyer

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Aluminum Grease Trough
Automatic (Gravity) Damper
Backdraft Damper Submittal
Curb Cap Adaptor Submittal
Curb Hinge Arrangement
Grease Grabber
Insect Screen
Motor Operated Damper
Roof Curb Submittal
Self-Flashing Curb Submittal
Solid State Speed Controls
Ventilation Gas Detectors Submittal IOM
Wall Mounting Kit Submittal
Wheel Cleaning Port

Ecowatt® Accessories

Constant Pressure System
Potentiometer Submittal
EC Motor Speed Control
EC Differential Pressure Control   IOM
ECM Multi-Speed Control   IOM

Miami Dade Certification
General Catalog Section
Ecowatt® Brochure
Submittal (All Variants)
IOM (STXD)
IOM (STXDe and STXDeRHUL)

STXD

  • General/Clean Air
  • Restaurant Hoods/Kitchen Ventilation
  • Fume and Smoke Removal
  • Laboratory Fume Hoods
  • Chemical Process Exhaust
