UBRD Remote Drive Upblast Propeller Roof Exhaust Fan

Roof Propeller Fan Series

UBRD Model

Model Features

  • Exhaust air up to 72,000 CFM in static pressure applications up to 1/2" w.g.
  • Straight-through airflow design results in maximum exhaust efficiency
  • Motor and drives are located outside of the exhaust airstream
  • Belt drives permit easy performance adjustments when needed
  • cULus 705 Listed

cULus Listed

Model Overview

UBRD units are high capacity belt driven roof mounted exhausters rated from 4,500 to 72,000 CFM. The motor and drives are located outside of the exhaust airstream, making these units especially suited for the removal of heated or contaminated air from commercial and industrial buildings or processes where these conditions exist. All models are capable of continuous operation exhausting air to 200°F.

The remote drive construction allows for easy rooftop belt and motor access for maintenance. For increased air performance (in clean conditions) with the same easy maintenance access, the UBRD is available without the belt and bearing enclosures.

Straight-through airflow design results in maximum exhaust efficiency. During operation, high air flow velocity opens butterfly dampers and prevents rain or snow from entering. Dampers close and cover the venturi opening when the unit is not in use.

The roof-mounted location eliminates interference with processes and equipment inside the building. It also permits locating the exhauster over a source of heated or contaminated air, allowing direct upward venting to the outside, unlike wall mounted exhausters which may move contaminated air through adjacent workspaces.

2-year fan housing warranty, 1-year motor warranty

Size CFM Range Max SP
24 4416 to 9200 1/2"
30 7812 to 14508 1/2"
36 10656 to 18816 1/2"
42 15624 to 27261 1/2"
48 16192 to 41216 1/2"
54 22990 to 49210 1/2"
60 25854 to 56730 1/2"
72 37665 to 72726 3/8"
Dimensional Drawing UBRD
Size A B C D E F G
24 30" 32" 30" 50" 22" 16" 31"
30 36" 38" 36" 54" 22" 16" 37"
36 42" 44" 42" 56" 22" 16" 43"
42 48" 50" 48" 59" 22" 16" 49"
48 54" 56" 54" 68" 22" 22" 55"
54 60" 62" 60" 70" 22" 22" 61"
60 66" 68" 66" 74" 22" 22" 67"
72 80" 82" 80" 86" 22" 22" 81"

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Description
Roof Curb
Outlet Guard
Disconnect Switches
Magnetic Latches
Heat/Smoke Vent
Extended Grease Lines

Description
UBRD Catalog Pages
UBRD Product Submittal
UBRD Product IOM

  • General/Clean Air
  • Contaminated Air
