ARE and ARS Dome Axial Power Roof Exhaust/Supply Fans

Roof Propeller Fan Series

ARE and ARS Models

Model Features

  • Exhaust air up to 2,827 CFM in static pressure applications up to 3/4" w.g.
  • Low profile attractive spun aluminum exterior
  • Direct drive units have low sound levels and quiet operation
  • AMCA Air and Sound Licensed
  • UL 705 Listed
  • This product meets the requirements of Buy American (2009) and Build America, Buy America (BABA), as part of IIJA (2022). Download letter here.

AMCA Air and Sound Licensed   UL Listed BABA-ACT

Model Overview

The AR series offers powerful axial exhaust (ARE) or supply (intake) (ARS) performance in a compact, lightweight and easy to install roof mounted design. Available in 4 model sizes, the AR series has a CFM range from 167 to 2,827 CFM, with static pressure capability up to 3/4".

The direct drive design has no belts or fan bearings to maintain or adjust and consequently requires very little maintenance. The AR series is an excellent choice for factories, shops, restaurants, bathrooms, offices, schools and other similar applications where light to moderate static pressures are present.

The low contour designs and all aluminum housing provide a modern, clean appearance in addition to excellent performance and durability.

5-year fan housing warranty, 1-year motor warranty

ARE Specifications

Size CFM Range Max SP
120A 521 to 1,804 3/4"
121A 207 to 1,220 1/2"
160A 685 to 2,606 3/4"
161A 455 to 1,782 1/2"
201A 584 to 2,827 3/4"

ARS Specifications

Size CFM Range Max SP
120A 206 to 1,445 3/4"
121A 163 to 974 1/4"
160A 303 to 2,187 3/4"
161A 442 to 1,754 1/2"
201A 1,254 to 2,627 3/8"
Dimensional Drawing ARE and ARS
Size A B C D E F
120A 121A 28" 16" 8" 3" 24" 15-3/4"
160A 161A 32" 18" 8-1/2" 3" 28" 19-3/4"
201A 36" 20" 9-3/4" 3" 32" 23-3/4"

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Insect Screen
Automatic (Gravity) Damper
Motor Operated Damper
Roof Curb
Curb Hinge Arrangement
Solid State Speed Controls
