TUB-HT Tubeaxial Upblast Propeller Roof Exhaust Fan for Heat and Smoke Removal

Roof Propeller Fan Series

TUB-HT Model

Model Features

  • Exhaust air up to 57,000 CFM in static pressure applications up to 3/4" w.g.
  • Motor and drives are located outside of the exhaust airstream
  • Designed and tested for emergency heat and smoke removal
  • Successfully passed heat test of 1000°F for 15 minutes and 500°F for over 4 hours
  • Belt drives permit easy performance adjustments when needed
  • UL 793 Listed as Power Ventilator for Smoke Control Systems

UL Listed

Model Overview

Tubeaxial Upblast Propeller Roof Exhauster for Heat and Smoke Removal Fans has been designed and tested for emergency heat and smoke removal. This design also lends itself to normal non-emergency high capacity industrial and commercial roof exhaust applications. TUB-HT's successfully passed heat tests of 1000°F for fifteen (15) minutes, and 500°F for over four (4) hours by an independent testing agency. TUB-HT exceeds I.R.I (Industrial Risk Insurers) guidelines and is UL-793 Listed as "Power Ventilator for Smoke Control Systems."

The heavy-gauge design allows for years of standard commercial use and the dependability required in a fire emergency. The upblast configuration exhausts heat and smoke high above the roof line aiding in the access and capabilities of firefighters. Unlike complete design dependence on gravity vents which are sometimes limited by air temperature and wind velocity, the TUB-HT in conjunction with gravity vents will more effectively remove smoke, hot air, and gases when used in a properly designed system. In the event of electrical failure, the 165°F fusible link will activate the spring assisted damper doors to provide gravity ventilation. Fan CFM, sizing and location for both exhaust and supply air is an essential part of the overall heat and smoke venting building design needs. Refer to I.R.I., NFPA (National Fire Protection Association), and local fire codes for help in proper system design. Final approval for the complete system design should be authorized by the local authority having jurisdiction.

Fan selections are available in 24, 30, 36, 42, 48, 54 and 60 inch sizes with horsepower up to 15 HP and CFM capabilities up to 57,000. Units are tested in accordance with AMCA Standard 301 (sound) and AMCA 210 (air) in an AMCA certified laboratory. Every unit is completely assembled, and factory tested for quality assurance prior to shipment.

1-year fan housing warranty, 1-year motor warranty

Size CFM Range Max SP
24 4035 to 8693 5/8"
30 6478 to 16225 3/4"
36 7444 to 20849 3/4"
42 11606 to 29490 3/4"
48 11132 to 36776 3/4"
54 18041 to 49325 3/4"
60 19438 to 57143 3/4"
Dimensional Drawing TUB-HT
Size A B C D E F G
24 30" 35" 25-1/8" 55-1/2" 25" 30-1/2" 37"
30 36" 41" 31-1/8" 58-1/2" 28" 30-1/2" 40"
36 42" 47" 37-1/8" 60-1/2" 30" 30-1/2" 43"
42 48" 53" 43-1/8" 65-1/2" 33" 32-1/2" 46"
48 54" 59" 49-1/8" 68-1/2" 36" 32-1/2" 49"
54 60" 65" 55-1/8" 71-1/2" 39" 32-1/2" 52"
60 66" 71" 61-1/8" 74-1/2" 42" 32-1/2" 55"

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Description
Roof Curb   Download
Outlet Guard   Download
Inspection Door   Download
Heat/Smoke Vent   Download
Disconnect Switches   Download

Description
TUB-HT Catalog Pages   Download
TUB-HT Product Submittal   Download
TUB-HT Product IOM   Download
