CWD Direct Drive Centrifugal Sidewall Exhaust Fan

Centrifugal Roof & Wall Fan Series

CWD Model

Model Features

  • Exhaust air up to 3,360 CFM in high static pressure applications up to 1" w.g.
  • Attractive spun aluminum exterior
  • Direct drive units have low sound levels and quiet operation
  • Non-overloading backward inclined wheel for efficiency at higher static pressures
  • AMCA Air and Sound Licensed
  • UL 705 Listed
  • This product meets the requirements of Buy American (2009) and Build America, Buy America (BABA), as part of IIJA (2022). Download letter here.

AMCA Air and Sound Licensed   UL Listed BABA-ACT

Model Overview

Centrifugal Wall Mounted Exhauster Direct Drive Fans (CWD) are designed to exhaust air up to 3,360 CFM, with high static pressure capability up to 1". The spun aluminum exterior provides a pleasing appearance, weatherproof construction, and resistance to corrosion. The low silhouette design is less noticeable on the building exterior, and the removable dome provides easy access to the fan interior for service and cleaning. The non-overloading backward inclined centrifugal wheel with its high static pressure capability makes it suitable for either ducted or non-ducted applications. It should be used where a sidewall mounted location is preferred to roof mounting. Direct drive units use smaller diameter wheels with lower RPM's, resulting in low sound levels and quieter operation. They have no belts or fan bearings to maintain or adjust and consequently require very little maintenance.

CWD's are used to exhaust relatively clean air from a variety of industrial, commercial and institutional buildings such as machinery and equipment rooms, storage areas, office buildings, restaurants, retail stores, schools and similar structures.

5-year fan housing warranty, 1-year motor warranty

Size CFM Range Max SP
7 66 to 254 1/2"
9 221 to 1320 1"
10 128 to 1591 1"
11 134 to 1805 1"
12 193 to 1583 7/8"
14 390 to 2585 1"
16 1032 to 3360 1"
Dimensional Drawing CWD
Size A B C D E F
7 15" 8" 5-15/16" 1-1/2" 8" 8"
9 26" 13-1/2" 11-15/16" 3" 15" 14"
10 26" 13-1/2" 11-15/16" 3" 15" 14"
11 30" 15-1/2" 13-15/16" 3" 17-1/2" 14"
12 30" 15-1/2" 13-15/16" 3" 17-1/2" 14"
14 36" 16-1/2" 17-15/16" 4" 22" 18"
16 36" 16-1/2" 17-15/16" 4" 22" 18"

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Solid State Speed Control
Motor Operated Damper
Automatic Damper

Centrifugal Roof and Sidewall Catalog
Typical Specification Sheet
Submittal
Instruction and Operation Manual

  • General/Clean Air
