HREB-C, HREB-P, and HRED-C Hooded Propeller Roof Exhaust Fans
Roof Propeller Fan Series
Model Features
- Exhaust air to over 90,000 CFM up to 1" w.g.
- Belt drives permit easy performance adjustments when needed.
- Direct drive units have low sound levels and quiet operation.
- Reversible blades available
- cULus 705 Listed (HREB-C, HREB-P, and HRED-C)
- AMCA Air and Sound Rated (HREB-C and HRED-C only)
- This product meets the requirements of Buy American (2009) and Build America, Buy America (BABA), as part of IIJA (2022). Download letter here.
Model Overview
Models HREB-C, HREB-P, and HRED-C are roof-mounted, low-profile exhaust fans rated from 4,000 to over 90,000 CFM with 1” static pressure. Eight sizes from 24-72 inches are available. Available in galvanized or aluminum construction, they are used to exhaust air from a variety of commercial and industrial operations such as manufacturing and assembly plants, warehouses, garages, laundries, and similar buildings.
For greater versatility, reversible blades are available as an option. Exhaust or supply air movement is achieved by a remote reversing switch. The reverse feature can provide positive or negative building pressurization with single or multiple fan units. The maximum utilization of the fans can be achieved with this inexpensive option.
The unit's low silhouette fits today's clean uncluttered building design and its standard all galvanized construction provides years of resistance to corrosion.Greater hood strength and weather resistance are achieved from the modular design. Heavy-gauge galvanized hood sections are cross broken and connected by a standing seam for extra strength over conventional hood designs.
The knockdown feature on the larger sizes provides lower transit costs and ease of Jobsite handling. This modular design is one of the strongest and easiest to assemble in the industry. Hood sizes 58 to 78 inch (represents fan sizes 24 to 36 inch) ship assembled. Hood sizes 87 to 123 inch (represent fan sizes 42 to 72 inch) ship knockdown or can be special ordered assembled.
For damper maintenance, an entire side panel of the fan stack easily removes for access. The hood hinges open for motor access. Belt drive fan units have outboard drives and adjustable motor bases for easy maintenance. The belt drive fan units all have outboard drives and adjustable motor bases for easy maintenance and motor access.
2-year fan housing warranty, 1-year motor warranty
HREB-C Specifications
| Size | CFM Range | Max SP |
| 24 | 1159 to 10347 | 3/4" |
| 30 | 3076 to 13542 | 3/4" |
| 36 | 2134 to 21737 | 3/4" |
| 42 | 3067 to 24690 | 3/4" |
| 48 | 8269 to 37349 | 3/4" |
| 54 | 13225 to 47674 | 3/4" |
| 60 | 10364 to 48414 | 3/4" |
HREB-P Specifications
| Size | CFM Range | Max SP |
| 24 | 4,165 to 11,411 | 1" |
| 30 | 5,453 to 16,168 | 1" |
| 36 | 5,154 to 23,833 | 1" |
| 42 | 8,030 to 30,856 | .875" |
| 48 | 11,146 to 48,266 | 1" |
| 54 | 14,222 to 53,524 | 1" |
| 60 | 17,983 to 67,200 | .875" |
| 72 | 31,785 to 93,240 | .875" |
HRED-C Specifications
| Size | CFM Range | Max SP |
| 24 | 1193 to 10288 | 3/4" |
| 30 | 2116 to 15195 | 3/4" |
| 36 | 3906 to 24839 | 3/4" |
| 42 | 7973 to 20253 | 3/4" |
| 48 | 7827 to 38005 | 3/4" |
| 54 | 9565 to 36365 | 3/4" |
| 60 | 30299 to 48780 | 3/4" |
| Size | A | B | C | D | E | F |
| 24 | 58" | 35" | 30" | 44" | 23" | 33-1/4" |
| 30 | 66" | 41" | 36" | 44" | 23" | 39-1/4" |
| 36 | 78" | 47" | 42" | 44" | 23" | 45-1/4" |
| 42 | 87" | 53" | 48" | 51" | 30" | 51-1/4" |
| 48 | 99" | 59" | 54" | 51" | 30" | 57-1/4" |
| 54 | 111" | 65" | 60" | 51" | 30" | 63-1/4" |
| 60 (DD) | 111" | 71" | 66" | 51" | 30" | 69-1/4" |
| 60 (BD) | 123" | 71" | 66" | 51" | 30" | 69-1/4" |
| 72 | 123 | 85 | 79 | 56 | 35 | 84-1/2 |
DD = Direct Drive | BD = Belt Drive
Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.
Standard Accessories
| Aluminum Construction | |
| Automatic (Gravity) Damper | |
| Birdscreen | |
| Disconnect Switches | |
| Extended Grease Lines | |
| Fiberglass Free Insulation | |
| Motor Operated Damper | Submittal |
| Motor Safety Chain | |
| Remote Drive | |
| Roof Curb | |
| Spring Assist Kit |
