PCV Value Series Models

Premium CHOICE Series by S&P

PCV Model

Model Features

  • Quiet operation 1.5 to 2.5 Sones
  • 50 and 80 CFM models
  • 4" duct connector with built-in backdraft damper
  • Robust steel housing
  • Attractive, sturdy grille
  • Thermally protected motor
  • cETLus Listed
  • Model PCV80 is ENERGY STAR® qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)

cETLus Listed   ENERGY STAR Qualified   HVI Certified   CALGreen (Title 24 Compliant)

Model Overview

The Value Series has the same great modular design as our full-size Premium CHOICE Fans at a lower price point. The PCV fans come in 2 sizes (PCV50 & PCV80) as fully assembled fans or in contractor packs with a housing 4-pack and a motor and grille 4-pack.

Contractor Pack

For simple installation, the PCV50 and PCV80 are available in four packs with the fan housings ready for installation first. After the drywall and painting are complete, the motor and grilles are available to finish the job. The housing kit includes the housing and hanger bars. The motor and grille kit consists of the motor plate, motor, wheel and standard grille.

Part Description
PCV50H PCV50 Contractor Pack Housing (4pk)
PCV50F PCV50 Contractor Pack Motor and Grille (4pk)
PCV80H PCV80 Contractor Pack Housing (4pk)
PCV80F PCV80 Contractor Pack Motor and Grille (4pk)

5-year warranty

Model Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight
PCV50 4" 50 - 2.5 120V / 60Hz 1.0 48.9 0.8A 7 lbs
PCV80 4" 80 60 1.5 120V / 60Hz 1.0 23.8 0.2A 7 lbs
Dimensional Drawing
Size X Y W D H
PCV50 11-13/16" 11-13/16" 9" 9" 5-3/4"
PCV80 11-13/16" 11-13/16" 9" 9" 5-3/4"

Plug-&-Play Grille Options

Lighted Grille Kit


PCVLK - CFL Lighted Grille Kit

  • 13 watt GU24 bulb (2700K/900 lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCVLEDK - LED Lighted Grille Kit

  • 13 Watt LED Light (4100K/1100 Lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Plug-&-Play Modules


PCHS - Humidity Sensor

  • Detects rapid rise in humidity
  • Auto-shut off timer
  • Accessible sensitivity adjustment
  • Humidity is sensed at the ceiling
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCSC - Speed Control

  • Compatible with PCV80
  • Accessible speed adjustment
  • High-speed override
  • Allows for adjustable continuous speed to meet ASHRAE 62.2
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Radiation Dampers & Kits

PCVRD Ceiling Radiation Damper SubmittalIOM
PCVLEDKRD Ceiling Radiation Damper with PCVLEDK

Electrical Controls

PC3S 3-Switch Control Submittal
FLTD-60 Fan/Light Delay Timer Switch Submittal
SRT-30 Rotary Spring Wound Timer Submittal
EPBT-60 Electronic Push Button Timer Submittal
FT622 ASHRAE 62.2 Bath Fan Ventilation Control Submittal
FT247 Programmable Fan Timer Submittal

General Accessories

PER-W Plastic Louvered Shutter Submittal
GRA Aluminum Exterior Fixed Grille Submittal
RC Roof Cap Submittal
ME Round Adjustable Metal Elbow Submittal
DC Duct Connector
WC Worm Clamp

Premium CHOICE Series Brochure
General Catalog Section
Connection Wiring Diagram (Premium CHOICE Series with AC Motor)


  • Residential Bathroom Exhaust
  • Commercial Bathroom Exhaust
  • Local Exhaust
  • Dwelling Unit Ventilation

How to Install Premium CHOICE Bathroom Fans
How to Wire Premium CHOICE Bathroom Fans
Premium CHOICE Plug-&-Play Options
