PCRL Recessed Vent Light Models

Premium CHOICE Series by S&P

PCRL Model

Model Features

  • Designed to look like a recessed can light
  • Quiet operation 1.2 Sones
  • PCRL80 has an E26 bulb base (bulb sold separately)
  • PCRL80F has a GU24 bulb base (CFL spiral bulb included)
  • Totally enclosed condenser motor for long life
  • Motor rated for 30,000 hours continuous on
  • Galvanized housing with black polyester powder coat finish
  • Universal 4 or 5" metal duct adaptor with built-in backdraft damper
  • 14-24" adjustable hanging bars
  • Fits 2x8 construction
  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified

cETLus Listed   ENERGY STAR Qualified   HVI Certified   Title 24

Model Overview

Designed to look like a recessed can light, this fan is certified to move 80 CFM at 0.1" SP. The PCRL gives you innocuous ventilation, a fan you can't see or hear!

5-year motor warranty

Model Duct Dia. Speed Setting HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight ENERGY STAR® Qualified
PCRL80 4" and
HS 80 50 1.5 120V 60Hz 4.1 19.7 0.27A 10 lbs Yes
PCRL80F 4" and
HS 80 50 1.5 120V 60Hz 4.1 19.7 0.27A 10 lbs Yes
Dimensional Drawing PCRL
Size W D H
PCRL80 12-5/8" 8" 7-1/4"
PCRL80F 12-5/8" 8" 7-1/4"

Light Cover Options


The Light Cover (PCRL80LC) comes standard with PCRL80F and is optional with PCRL80. The light cover disguises a spiral or non-PAR30 bulb to keep the recessed can light look.

Plug-&-Play Modules

PCHS - Humidity Sensor

  • Detects rapid rise in humidity
  • Auto-shut off timer
  • Accessible sensitivity adjustment
  • Humidity is sensed at the ceiling
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCSC - Speed Control

  • Accessible speed adjustment
  • High-speed override
  • Allows for adjustable continuous speed to meet ASHRAE 62.2
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Electrical Controls

Part Description
PC3S 3-Switch Control   Download
FLTD-60 Fan/Light Delay Timer Switch   Download
SRT-30 Rotary Spring Wound Timer   Download
EPBT-60 Electronic Push Button Timer   Download
FT622 ASHRAE 62.2 Bath Fan Ventilation Control   Download
FT247 Programmable Fan Timer   Download

General Accessories

Part Description
PER-W Plastic Louvered Shutter   Download
GRA Aluminum Exterior Fixed Grille   Download
RC Roof Cap   Download
ME Round Adjustable Metal Elbow   Download
DC Duct Connector   Download
WC Worm Clamp   Download

Premium CHOICE Series Brochure   Download
PCRL Catalog Pages   Download
PCRL Product Submittal   Download
PCRL Product IOM   Download

PCRL80 Revit File
PCRL80F Revit File

  • General/Clean Air

How to Install an S&P PC Fan
How to Wire S&P Premium CHOICE Bathroom Fans
Premium CHOICE Series Plug-&-Play Options
