PCLP Low Profile Models

Premium CHOICE Series by S&P

PCLP Model

Model Features

  • Low profile housing design
  • Quiet operation 1.2 to 2.0 Sones
  • Enclosed condenser motor for long life
  • Motor rated for 30,000 hours continuous on
  • Built-in backdraft damper
  • Robust steel housing
  • Attractive, sturdy grille
  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)

cETLus Listed   ENERGY STAR Qualified   HVI Certified   CALGreen (Title 24 Compliant)

Model Overview

The Premium CHOICE Low Profile Ventilation fans feature ultra-low profile housings suitable for both wall and ceiling installations. Installing a PCLP in a wall means that you do not need a radiation damper to meet fire-resistance requirements in the building code like you do when installing the fan in a fire-rated ceiling making the PCLP the more economical CHOICE for multi-family applications.

Contractor Pack

For simple installation, the PCLP is available in four packs with the fan housings ready for installation first. After the drywall and painting are complete, the motor and grilles are available to finish the job. The housing kit includes the housing and hanger bars. The motor and grille kit consists of the motor plate, motor, wheel and standard grille.

Part Description
PCLP PCLP80 Contractor Pack Housings (4pk)
PCLP80F PCLP80 Contractor Pack Motor and Grille (4pk)
PLCP100F PCLP100 Contractor Pack Motor and Grille (4pk)

5-year warranty

Model Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight
PCLP80 4" 80 62 1.2 120V / 60Hz 3.1 25.9 0.35A 7 lbs
PCLP100 4" 100 86 2 120V / 60Hz 4.1 24.6 0.40A 7 lbs
Dimensional Drawing PCLP
Size X Y W D H
PCLP80 13" 14" 10-1/4" 10-1/4" 3-3/4"
PCLP100 13" 14" 10-1/4" 10-1/4" 3-3/4"

Plug-&-Play Grille Options

Lighted Grille Kit

PCLPLEDK - LED Lighted Grille Kit

  • 11 watt LED array (4100K/1100 lumens)
  • 2 watt LED night light setting (200 lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Plug-&-Play Modules

PCLPHS - Humidity Sensor

  • Detects rapid rise in humidity at the ceiling level
  • Automatic shut-off timer
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCLPSC - Speed Control

  • Accessible speed adjustment
  • High-speed override
  • Allows for adjustable continuous speed to meet ASHRAE 62.2
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Electrical Controls

Part Description
PC3S 3-Switch Control
FLTD-60 Fan/Light Delay Timer Switch
SRT-30 Rotary Spring Wound Timer
EPBT-60 Electronic Push Button Timer
FT622 ASHRAE 62.2 Bath Fan Ventilation Control
FT247 Programmable Fan Timer

General Accessories

Part Description
PER-W Plastic Louvered Shutter
GRA Aluminum Exterior Fixed Grille
RC Roof Cap
ME Round Adjustable Metal Elbow
DC Duct Connector
WC Worm Clamp

Description
Premium CHOICE Series Brochure
PCLP Catalog Pages
PCLP Product Submittal
PCLP Product IOM
PC Connection Wiring Diagrams for AC Motor

Description
PCLP80 Revit File
PCLP100 Revit File

  • Residential Bathroom Exhaust
  • Commercial Bathroom Exhaust
  • Local Exhaust
  • Dwelling Unit Ventilation
