PC Standard Size Models with AC Motors

Premium CHOICE Series by S&P

PC-SILENT Model

Model Features

  • Extremely quiet operation <0.3 to 1.1 Sones
  • Enclosed condenser motor for long life
  • Motor rated for 30,000 hours continuous on 120V/60Hz, 230V/60Hz or 230V/50Hz motors
  • 4" (PC50X), 4 & 6" (PC80X & PC110X), and 6" (PC150) duct connectors included with built-in backdraft damper
  • Robust steel housing
  • Attractive, sturdy grille
  • UL Listed
  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)
  • AMCA Air and Sound Licensed

UL Listed   cETLus Listed   ENERGY STAR Qualified   HVI Certified   CALGreen (Title 24 Compliant)   AMCA Air and Sound Licensed

Model Overview

Available in 4 sizes with single speed motors (PC50X, PC80X, PC110X, and PC150) the Premium CHOICE AC Standard Models, as the name suggests, is all about the CHOICE! The fans are engineered to accept S&P's PC plug-&-play options: lighted or motion sensing grille kits, and humidity sensing module, VOC sensing module, speed control module, or Bluetooth® speaker module. One fan can be modified to be the exact fan need. You even have the CHOICE to add a control or change the grille after the initial installation.

Contractor Pack

For simple installation, the PC80X and PC110X are available as four packs with the fan housings ready for installation first. After the drywall and painting are complete, the motor and grilles are available to finish the job. The housing kit includes the housing and hanger bars. The motor and grille kit consists of the motor plate, motor, wheel and standard grille.

Part Description
PCH PC80X and PC110X Contractor Pack Housing (4pk)
PC80F PC80X Contractor Pack Motor and Grille (4pk)
PC110F PC110X Contractor Pack Motor and Grille (4pk)

5-year warranty

Model Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight
PC50X 4" 50 38 0.9 120V / 60Hz 3.6 16 0.2A 7 lbs
PC80X 4" 70 55 1.3 120V / 60Hz 2.9 24 0.27A 10 lbs
6" 90 65 0.5 3.6 25
PC110X 4" 91 110 0.9 120V / 60Hz 3.3 27.3 0.30A 11 lbs
6" 109 130 0.9 3.9 27.6
PC150 6" 150 131 1.1 120V / 60Hz 3.5 43.2 0.34A 11 lbs
Dimensional Drawing
Size X Y W D H
PC50X 11-7/16" 11-13/16" 9" 9" 5-3/4"
PC80X 13" 14" 11-3/8" 10-1/2" 7-5/8"
PC110X 13" 14" 11-3/8" 10-1/2" 7-5/8"
PC150 13" 14" 11-3/8" 10-1/2" 7-5/8"

Plug-&-Play Grille Options

Metal Grille

PCMG - Metal Grille

  • 13 x 14" metal grille
  • Ideal for commercial applications

Lighted Grille Kit

PCLK - CFL Lighted Grille Kit

  • 13 watt GU24 bulb (2700K/900 lumens)
  • 4 watt night light bulb
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCLEDK - LED Lighted Grille Kit

  • 11 watt LED array (4100K/1100 lumens)
  • 2 watt LED night light setting (200 lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Sensing Grille Kit

PCMK - Motion Sensing Grille Kit

  • Automatically turns on fan when motion is sensed
  • Adjustable Time Delay Shut-Off from 3 to 30 Minutes
  • Adjustable Speed reduced up to 50%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCLMK - Motion Sensing Lighted Grille Kit

  • 13 Watt GU24 Bulb (2700K/900 Lumens)
  • 4 Watt Night Light Bulb
  • Automatically turns on fan when motion is sensed
  • Adjustable Time Delay Shut-Off from 3 to 30 Minutes
  • Adjustable Speed reduced up to 50%
  • Simple Plug-In Receptacle in Fan Housing
  • Can be installed with New or Pre-Installed Fan

PCMHK - Motion and Humidity Sensing Grille Kit

  • Automatically turns fan on when motion and/or rapid rise in humidity is sensed at the ceiling level
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Adjustable time delay shut-off from 3 to 30 minutes
  • Adjustable speed reduced up to 50%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCLMHK - Motion & Humidity Sensing Lighted Grille Kit

  • 13 watt GU24 bulb (2700K/900 lumens)
  • 4 watt night light bulb
  • Automatically turns fan on when motion and/or rapid rise in humidity is sensed at the ceiling level
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Adjustable time delay shut-off from 3 to 30 minutes
  • Adjustable speed reduced up to 50%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Plug-&-Play Modules

PCHS - Humidity Sensor

  • Detects rapid rise in humidity at the ceiling level
  • Automatic shut-off timer
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCSC - Speed Control

  • Accessible speed adjustment
  • High speed override
  • Allows for adjustable continuous speed to meet ASHRAE 62.2
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCIAQS - IAQ Sense, VOC/Humidity Sensor

  • Detects VOCs and/or rapid rise in humidity at the ceiling level
  • Semi-conductor gas sensor, detecting a wide range of VOCs
  • Monitoring range is 400-2000 PPM equivalent CO2
  • Speed control for adjustable continuous speed to meet ASHRAE 62.2
  • Integrated control switch to turn features On/Off
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCBTS - Bluetooth® Wireless Speaker

  • High quality Bluetooth® wireless speaker
  • Easy pairing with most Bluetooth® - enabled devices
  • After initial pairing, connection to device is automatic
  • 30 foot Bluetooth® range
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Radiation Dampers & Kits

Part Description
PCRD Ceiling Radiation Damper   Download
PCMKRD Ceiling Radiation Damper Kit with PCMK   Download
PCMHKRD Ceiling Radiation Damper Kit with PCMHK   Download
PCLKRD Ceiling Radiation Damper Kit with PCLK   Download
PCLEDKRD Ceiling Radiation Damper Kit with PCLEDK   Download
PCLMKRD Ceiling Radiation Damper Kit with PCLMK   Download
PCLMHKRD Ceiling Radiation Damper Kit with PCLMHKRD   Download
PCMGKRD Ceiling Radiation Damper Kit with PCMG   Download

Electrical Controls

Part Description
PC3S 3-Switch Control   Download
FLTD-60 Fan/Light Delay Timer Switch   Download
SRT-30 Rotary Spring Wound Timer   Download
EPBT-60 Electronic Push Button Timer   Download
FT622 ASHRAE 62.2 Bath Fan Ventilation Control   Download
FT247 Programmable Fan Timer   Download

General Accessories

Part Description
PER-W Plastic Louvered Shutter   Download
GRA Aluminum Exterior Fixed Grille   Download
RC Roof Cap   Download
ME Round Adjustable Metal Elbow   Download
DC Duct Connector   Download
WC Worm Clamp   Download

Replacement Parts

Part Description
PCDC4 Replacement 4" Duct Connector   Download
PCDC6 Replacement 6" Duct Connector   Download

Description
Premium CHOICE Series Brochure   Download
PC Catalog Pages   Download
PC50X Product Submittal   Download
PC80X Product Submittal   Download
PC110X Product Submittal   Download
PC150 Product Submittal   Download
PC50X Product IOM   Download
PC80X, PC110X, and PC150 Product IOM   Download
PC80X, PC110X and PC150 Product IOM (230V)   Download
PC Connection Wiring Diagrams for AC Motor   Download

Description
PC80X Revit File Download
PC110X Revit File Download
PC150 Revit File Download
PCRD Radiation Damper Revit File Download

  • Residential Bathroom Exhaust
  • Commercial Bathroom Exhaust
  • Local Exhaust
  • Dwelling Unit Ventilation
