TD-MIXVENT by S&P In-line Mixed Flow Duct Fan

In-line/Sidewall Duct Fan Series

TD-MIXVENT Model

Model Features

  • Exhaust air up to 2,630 CFM with static pressure capabilities to 1" w.g.
  • Mixed flow impeller for excellent airflow to pressure performance ratio
  • Ideal for applications where space is limited
  • AMCA Seal for Air Performance
  • cULus Listed
  • ENERGY STAR® qualified

AMCA Seal for Air Performance   cULus Listed   ENERGY STAR Qualified   Title 24   HVI Certified

Model Overview

The TD-MIXVENT series are in-line duct fans specially designed to maximize the airflow performance with minimal noise levels in a small, compact housing. This makes the TD-MIXVENT series the ultimate solution for small to medium sized ventilation installations which require a high airflow to pressure ratio and occupy minimum space (e.g., false ceiling voids, cabinets and many other limited space environments).

TD-MIXVENT's have been designed with the professional contractor/engineer in mind. All models include a "removable body" feature that enables the motor-impellor assembly to be completely removed or replaced without the need to interfere with the attached ducting. These models incorporate a powerful mixed flow impeller and internal air vanes located at the discharge end of the fan housing. This impeller and guide vane combination provides a smooth laminar air flow which in turn minimizes turbulence and noise and generates excellent airflow to static pressure performance ratio.

The unique design of the support brackets allows the motor and impeller assembly to be fitted or removed without dismantling the adjacent ducting, therefore facilitating any installation or maintenance. The internal aerodynamic design of the fan enables the unit to generate large air volumes and pressures with the minimum of in-duct or radiated noise. As an additional standard advantage, TD-MIXVENT fans are fitted with a direct connection two-speed motor. These fans offer an ideal in-line duct fan solution for a wide range of HVAC ventilation applications.

5-year fan housing warranty, 5-year motor warranty

LS = Low Speed / HS = High Speed

Size Duct Dia. Max. CFM Nom. RPM Voltage / Frequency Max. Watts Current (Amps) Max. SP Max. Temp. of Transported Air Avg. Ship Weight
100 4" 101 2516 120V / 60Hz 26 0.45 0.4" 104°F 4 lbs
100X1 4" 135 2500 120V / 60Hz 33 0.24 0.55" 104°F 6 lbs
125 5" 197 2146 120V / 60Hz 38 0.72 0.55" 104°F 6 lbs
150 6" 293 2289 120V / 60Hz 65 0.54 1.15" 140°F 9 lbs
200 8" 538 2781 120V / 60Hz 184 0.8 1.625" 140°F 13 lbs
250 LS 10" 541 2400 115V / 60Hz 162 2.2A 2.03" 140°F 21 lbs
250 HS 10" 754 3200 115V / 60Hz 241 2.2A 2.53" 140°F 21 lbs
315 LS 12.4" 751 2000 115V / 60Hz 208 2.3A 1.65" 140°F 31 lbs
315 HS 12.4" 1050 2500 115V / 60Hz 335 2.3A 2.95" 140°F 31 lbs
355 14" 2089 1536 115V / 60Hz 522 3.9A 1.0" 140°F 68 lbs
400 16" 3124 1559 115V / 60Hz 916 6.3A 1.2" 140°F 78 lbs
Dimensional Drawing TD-MIXVENT - Size 100 to 315

TD-MIXVENT Specifications (Size 100 to 315)

Size X A B C D E F G H
100 5-15/16" 9-1/8" 5-7/16" 3-3/4" 3-7/8" 3-1/4" 3-3/4" 1-7/8" 2-1/16"
100X1 7-3/8" 11-15/16" 6-15/16" 4-1/2" 3-13/16" 3-15/16" 3-9/16" 3-1/8" 2-3/8"
125 7-3/8" 10-3/16" 6-15/16" 4-1/2" 4-13/16" 3-15/16" 3-9/16" 3-1/8" 2-3/8"
150 8-3/8" 11-5/8" 7-7/8" 5" 5-13/16" 4-7/16" 5-1/8" 3-1/8" 2-3/8"
200 9-3/16" 11-7/8" 8-9/16" 5-9/16" 7-13/16" 4-7/8" 5-1/2" 3-15/16" 3-11/16"
250 11-7/16" 15-3/16" 10-11/16" 7-9/16" 9-3/4" 6-1/8" 6-5/8" 5-11/16" 5-1/2"
315 14" 17-11/16" 13-1/4" 8-13/16" 12-5/16" 7-3/8" 8-1/4" 7-3/16" 7"
Dimensional Drawing TD-MIXVENT - Size 355 to 400

TD-MIXVENT Specifications (Size 355 to 400)

Size A B C D E F G H I J K
355 14-13/16" 9-3/8" 17-3/4" 8-13/16" 16-3/4" 13-15/16" 6-5/16" 14-1/2" 18-11/16" 13-3/8" 5/16"
400 16" 9-13/16" 19-3/8" 10-1/2" 19-3/16" 15-11/16" 6-5/16" 16-3/4" 21-1/2" 14-9/16" 5/16"

TD-MIXVENT Fan Kits

The TD-MIXVENT fan kits provide all the hardware needed to complete a simple in-line ducted ventilation installation. The kit includes a powerful TD in-line fan, exterior grilles and interior grilles (with or without lights).

Standard Exhaust Kit

KIT-TD100

  • 1 TD100 exhaust fan
  • 1 plastic round grille (PG-100)
  • 1 exterior louvered grille (PER-100W)
  • Integral mounting bracket

KIT-TD150

  • 1 TD150 exhaust fan
  • 1 plastic round grille (PG-150)
  • 1 exterior louvered grille (PER-150W)
  • Integral mounting bracket

Deluxe Exhaust Kit

KIT-TD150-DV

  • 1 TD150 exhaust fan
  • 2 plastic round grilles (PG-150)
  • 1 exterior louvered grille (PER-150W)
  • 1 Y-fitting (SY-6)
  • Integral mounting bracket

Lighted Deluxe Exhaust Kit

KIT-TD150L

  • 1 TD150 exhaust fan
  • 2 Vent Lights with LED Bulb (VLED-100)
  • 1 Y-fitting (SY44-6)
  • Integral mounting bracket

KIT-TD150H

  • 1 TD150 exhaust fan
  • 2 Vent Lights with Halogen Bulb (VLH-100)
  • 1 Y-fitting (SY44-6)
  • Integral mounting bracket

KIT-TD150F

  • 1 TD150 exhaust fan
  • 2 Vent Lights with Fluorescent Bulb (VLF-100)
  • 1 Y-fitting (SY44-6)
  • Integral mounting bracket

Outside Air Kit

OSAK-125

  • 1 TD125 exhaust fan
  • 1 CAR-125 steel backdraft damper
  • 1 FT247 programmable fan timer

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Part Description
BOC Interior Air Valve Metal
BOR Interior Air Valve Plastic
CAR Metal Backdraft Damper
EPBT-60 Electronic Push Button Timer
FB Filter Box
FT247 Programmable Fan Timer
FT622 ASHRAE 62.2 Bath Fan Ventilation Control
GRA Aluminum Exterior Fixed Grille
MCA Backdraft Damper
MBR Connection Flange
PER-CN High-Pressure Aluminum Louver Shutter
PER-W Plastic Louvered Shutter
PG Premium Grille/Collar
SC Speed Control
SCS5 Speed Control Slide Type
SIL Acoustic Attenuators
SR Reducer
SY Y Sheet Metal Adapter
VL Vent Light
