PV-POWERVENT by S&P In-line Centrifugal Duct Fan

In-line/Sidewall Duct Fan Series

PV-POWERVENT Model

Model Features

  • Exhaust air up to 942 CFM with static pressure capabilities to 1-1/2" w.g.
  • Galvanized steel casing with black baked enamel coating
  • Pre-wired junction box
  • Ideal for applications where space is limited
  • Non-overloading backward inclined wheel for efficiency at higher static pressures
  • AMCA Seal for Air Performance
  • cULus Listed

AMCA Seal for Air Performance   cULus Listed   ETL Listed

Model Overview

The POWERVENT (PV) series of direct drive centrifugal in-line duct ventilation fans consists of twelve model sizes 4", 5", 6", 8", 10" and 12.4" respectively. All models are designed for direct connection in-line with standard diameter round ducting. Airflow performance values range from 108 CFM (PV-100) up to 942 CFM (PV-315X).

All PV fan models incorporate a powerful external rotor motor that has been factory matched to a non-overloading backward curved centrifugal fan wheel.

This powerful combination enables the fan to deliver exceptional airflow performances against high static pressure typically found in ducted ventilation systems. All motors within PV fans are fully speed controllable using voltage or frequency control regulators.

The PV series of duct exhaust or supply fans have been specifically designed for simple installation and many years of maintenance-free operation. These fans can be mounted at any angle and any point along the duct. The totally enclosed motor design allows the PV fans to operate in high moisture, lint, and dust-laden air. All models are manufactured with high-quality materials and artistry that is supported by a comprehensive five (5) year warranty.

All PV Fans feature a corrosion resistant galvanized steel casing with black baked enamel coating and are supplied with a strong mounting bracket and prewired junction box.

The PV100X fans feature Class F motor insulation.

5-year fan housing warranty, 5-year motor warranty

Size Duct Dia. Max. CFM Nom. RPM Voltage Frequency Max. Watts Current Max. SP Max. Temp. of Transported Air Avg. Ship Weight
100 4" 108 1400 115V 60Hz 57W 0.52A 1.7" 140°F 7 lbs
100X 4" 153 2880 115V 60Hz 84W 0.8A 1.85" 140°F 7 lbs
125 5" 128 2350 115V 60Hz 58W 0.52A 1.43" 140°F 7 lbs
125X 5" 206 2745 115V 60Hz 85W 0.8A 1.77" 140°F 7 lbs
150 6" 245 2750 115V 60Hz 78W 0.8A 1.2" 140°F 11 lbs
150X 6" 390 2700 115V 60Hz 130W 1.0A 2.05" 140°F 11 lbs
200 8" 402 3100 115V 60Hz 130W 1.0A 1.94" 140°F 11 lbs
200X 8" 544 2930 115V 60Hz 180W 1.76A 2.64" 140°F 11 lbs
250 10" 568 3000 115V 60Hz 170W 1.76A 2.61" 140°F 13 lbs
250X 10" 618 3045 115V 60Hz 214W 1.5A 2.8" 140°F 13 lbs
315 12.4" 654 2600 115V 60Hz 170W 1.5A 2.21" 140°F 21 lbs
315X 12.4" 942 2650 115V 60Hz 370W 2.4A 3.9" 140°F 21 lbs
Dimensional Drawing PV-POWERVENT
Size ø A ø B C D E F ø G
100 3-13/16" 3-13/16" 4-3/4" 7-11/16" 7-1/2" 4-3/4" 9-9/16"
100X 3-13/16" 3-13/16" 4-3/4" 7-11/16" 7-1/2" 4-3/4" 9-9/16"
125 4-13/16" 4-13/16" 4-3/4" 7-13/16" 7-1/2" 4-3/4" 9-9/16"
125X 4-13/16" 4-13/16" 4-3/4" 7-13/16" 7-1/2" 4-3/4" 9-9/16"
150 5-13/16" 5-13/16" 4-3/4" 8-7/16" 9-5/16" 4-3/4" 13-1/8"
150X 5-13/16" 5-13/16" 4-3/4" 8-7/16" 9-5/16" 4-3/4" 13-1/8"
200 7-13/16" 7-13/16" 4-3/4" 8-3/4" 9-5/16" 4-3/4" 13-1/8"
200X 7-13/16" 7-13/16" 4-3/4" 8-3/4" 9-5/16" 4-3/4" 13-1/8"
250 9-3/4" 9-3/4" 4-3/4" 8-1/16" 9-5/16" 4-3/4" 13-1/8"
250X 9-3/4" 9-3/4" 4-3/4" 8-1/16" 9-5/16" 4-3/4" 13-1/8"
315 12-15/16" 12-15/16" 4-3/4" 9-3/16" 10-9/16" 4-3/4" 15-13/16"
315X 12-15/16" 12-15/16" 4-3/4" 9-3/16" 10-9/16" 4-3/4" 15-13/16"

PV-POWERVENT Fan Kits

The PV-POWERVENT Series fans are also available as easy-to-install kits. This ultra-powerful bathroom fan offers a choice of single or dual vent exhaust. These kits are used for installations that require long or complicated duct runs.

Standard Exhaust Kit

KIT-PV100

  • 1 PV100 exhaust fan
  • 1 plastic round grille (PG-100)
  • Mounting bracket

KIT-PV100X

  • 1 PV100X exhaust fan
  • 1 plastic round grille (PG-100)
  • Mounting bracket

KIT-PV150

  • 1 PV150 exhaust fan
  • 1 plastic round grille (PG-150)
  • Mounting Bracket

Deluxe Exhaust Kit

KIT-PV100X-DV

  • 1 PV100X exhaust fan
  • 2 plastic round grilles (PG-100)
  • 1 Y-fitting (SY-4)
  • Mounting Bracket

KIT-PV150-DV

  • 1 PV150 exhaust fan
  • 2 plastic round grilles (PG-150)
  • 1 Y-fitting (SY-6)
  • Mounting Bracket

KIT-PV200-DV

  • 1 PV200 exhaust fan
  • 2 plastic round grilles (BOR-200)
  • 1 Y-fitting (SY-8)
  • Mounting Bracket

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Part Description
BOR/BOC Round Plastic/Metal Adjustable Grille   Download
CS-325 Current Sensor   Download
EPBT-60 Electronic Push Button Timer   Download
FB Filter Box   Download
GRA Aluminum Exterior Fixed Grille   Download
LT-100 Lint Trap   Download
PER-CN High-Pressure Aluminum Louver Shutter   Download
PER-W Plastic Louvered Shutter   Download
PG Premium Grille/Collar   Download
SC Speed Control   Download
SCS5 Speed Control Slide Type   Download
SIL Acoustic Attenuators   Download
SPT-100X Pressure Sensor   Download
SR Reducer   Download
SY Y Sheet Metal Adapter   Download
VL Vent Light   Download

Description
Inline Fans Options Brochure   Download
PV-POWERVENT Catalog Pages   Download
PV-POWERVENT Product Submittal   Download
PV-POWERVENT IOM   Download
