TRC by S&P Total Recovery for All Climates (Commercial Applications)

Energy Recovery Ventilators

TRC Model

Model Features

  • MERV-8 filters
  • Transformer/relay package allowing simple on/off control
  • Access doors for easy access to blowers, core, and filters
  • Fully insulated case
  • Large cores for high efficiency
  • No condensate pan or drain required
  • AHRI Certified
  • cULus Listed

AHRI Certified   cULus Listed

Model Overview

With S&P's TRC (total recovery for commercial applications) Series for all climates, stale room air is exhausted, and the fresh outdoor air is brought back into the building. With this line of ERVs (Energy Recovery Ventilators) these two air streams are directed through a highly developed "air-to-air" energy exchange core. The air streams are physically separated by many layers of "plates" so there is no mixing or contamination of the fresh air. The plates are made of an engineered "resin" material that simultaneously transfers heat by conduction and humidity by attracting and moving water vapor from one air stream to the other.

S&P's TRCs moderate extremes in both temperature and humidity, creating a comfortable indoor environment. The unique moisture transfer capability of the S&P core also eliminates condensation and frost build up in most applications. Unlike other ERVs on the market no mechanical or electrical defrost systems are needed, which means higher heat recovery efficiencies, easier installation and more reliable operation.

10-year core warranty, 2-year unit warranty

Core Performance for TRC500

Airflow CFM ESP in H2O Watts Temp. EFF% Total EFF% Winter/Summer
225 1.25 335 81 76/66
338 1.00 420 77 71/61
380 0.90 470 75 69/59
450 0.65 550 73 66/56
540 0.25 640 70 62/52
575 0.00 690 69 61/51
600 -0.25 735 68 60/50

Airflow Performance for TRC800

Motor HP
Phase
External Static Pressure (Inches Water Column)
0 0.25 0.5 0.75 0.9 1.25 1.5
0.75
Single Phase
970 CFM 925 CFM 860 CFM 795 CFM 750 CFM 635 CFM 480 CFM
1,490 Watts 1,375 Watts 1,270 Watts 1,160 Watts 1,090 Watts 950 Watts 825 Watts

Airflow Performance for TRC1200

Motor HP
Phase
External Static Pressure (Inches Water Column)
0 0.25 0.5 0.75 0.9 1.25 1.5
1.0
Single Phase
1,575 CFM 1,470 CFM 1,350 CFM 1,225 CFM 1,090 CFM 950 CFM 795 CFM
1,545 Watts 1,525 Watts 1,500 Watts 1,475 Watts 1,435 Watts 1,380 Watts 1,300 Watts
1.0
Three Phase
1,675 CFM 1,570 CFM 1,435 CFM 1,280 CFM 1,115 CFM 940 CFM 760 CFM
1,410 Watts 1,400 Watts 1,380 Watts 1,340 Watts 1,280 Watts 1,210 Watts 1,135 Watts

Airflow Performance for TRC1600

Motor HP Blower RPM Turns Open External Static Pressure (in w.g.)
0 0.25 0.5 0.75 0.9 1.25 1.5
SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP
1.5 1148 4 1592 0.7 1480 0.7 1320 0.6 1120 0.5 800 0.4 - - - -
1304 2 1809 1.0 1720 1.0 1600 0.9 1410 0.8 1250 0.7 975 0.6 630 0.4
1460 0 2025 1.5 1950 1.4 1845 1.3 1715 1.2 1540 1.1 1400 1.0 1165 0.8

Dimensions for TRC500

Dimensional Drawing TRC500

Dimensions for TRC800

Dimensional Drawing TRC800

Dimensions for TRC1200

Dimensional Drawing TRC1200

Dimensions for TRC1600

Dimensional Drawing TRC1600

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Part Description
STC7D-W Digital Time Clock - Wall Mount   Download
SMC-C Motion (Occupancy) Control - Ceiling Mount   Download
SCO2-W Carbon Dioxide Control - Wall Mount   Download
SHW-20 Dehumidistat   Download
45EVT10 10" Round Flange Kit (2 in Kit) for TRC500   Download
BD10 Indoor 10" Round Backdraft Damper for TRC500   Download
BD12 Indoor 12" Round Backdraft Damper for TRC800   Download
FA10-G 10" round galvanized metal wall cap for TRC500   Download
FA12-G 12" round galvanized metal wall cap for TRC800   Download
FA10-P 10" round paintable metal wall cap for TRC500   Download
FA12-P 12" paintable metal wall cap for TRC800   Download
VW12X12-G 12x12" louver to 10" round galvanized metal wall cap for TRC500   Download
990080 MERV8 14x20x2" filter (Single) for TRC500   Download
990091 MERV8 14x20x2" filter (Case of 12) for TRC500   Download
990083 MERV8 20x20x2" filter (Single) for TRC800 & 1600   Download
990084 MERV8 20x20x2" filter (Case of 12) for TRC800 & 1600   Download

Description
Total Recovery Ventilators Brochure   Download
TRC Catalog Pages   Download
TRC500 Product Submittal   Download
TRC800 Product Submittal   Download
TRC1200 Product Submittal   Download
TRC1600 Product Submittal   Download
TRC500 IOM   Download
TRC800 IOM   Download
TRC1200 IOM   Download
TRC1600 IOM   Download

Description
TRC500 Revit File
TRC800 Revit File
TRC1200 Revit File
TRC1600 Revit File
