TR by S&P Total Recovery for All Climates

Energy Recovery Ventilators

TR Model

Model Features

  • MERV-8 filters
  • Less than 1-watt standby power consumption
  • Transformer/relay package allowing simple on/off control
  • Plastic double collars for 6 or 8" direct duct connection (TR300 is 8" only)
  • TR90, TR130, TR300 have painted case, low voltage controls, 3' Power cord
  • TR90G has galvanized case, line voltage, and no line cord
  • Integral mounting flange and hanging bracket system
  • Fully insulated case
  • Large cores for high efficiency
  • No condensate pan or drain required
  • HVI Certified
  • cULus Listed

HVI Certified   cULus Listed

Model Overview

To protect the two most valuable investments of your life, your home, and your family, improving indoor air quality is key. With S&P's TR (total recovery) Series for all climates, stale room air is exhausted, and the fresh outdoor air is brought back into the house. With this line of ERVs (Energy Recovery Ventilators) these two air streams are directed through a highly developed "air-to-air" energy exchange core. The air streams are physically separated by many layers of "plates" so there is no mixing or contamination of the fresh air. The plates are made of an engineered "resin" material that simultaneously transfers heat by conduction and humidity by attracting and moving water vapor from one air stream to the other.

S&P's TRs moderate extremes in both temperature and humidity, creating a comfortable indoor environment. The unique moisture transfer capability of the S&P core also eliminates condensation and frost build up in most applications. Unlike other ERVs on the market no mechanical or electrical defrost systems are needed, which means higher heat recovery efficiencies, easier installation and more reliable operation.

WARNING: This product can expose you to chemicals including formaldehyde, which is known to the State of California to cause cancer. For more information go to

10-year core warranty, 5-year unit warranty

Core Performance for TR90/90G

Airflow CFM ESP in H2O Temp. EFF% Total EFF% Winter Total EFF% Summer
40 0.60 84 74 56
58 0.50 80 69 50
73 0.40 77 65 46
85 0.30 74 62 43
98 0.20 71 59 39
113 0.10 68 56 34

Core Performance for TR130

Airflow CFM ESP in H2O Temp. EFF% Total EFF% Winter/Summer
52 0.70 83 75/60
69 0.60 80 72/57
94 0.50 76 67/52
113 0.40 73 64/48
132 0.30 70 60/44
141 0.20 68 59/43
148 0.10 67 57/41

Core Performance for TR200

Airflow CFM ESP in H2O Temp. EFF% Total EFF% Winter/Summer
122 0.70 82 74/59
149 0.65 80 72/56
168 0.50 79 70/55
176 0.40 78 69/54
186 0.30 77 68/53
192 0.20 77 68/52
200 0.10 76 67/52

Core Performance for TR300

Airflow CFM ESP in H2O Temp. EFF% Total EFF% Winter/Summer
155 1.0 80 70/51
199 0.9 76 67/48
249 0.8 72 62/44
268 0.7 71 61/42
289 0.6 69 58/39
300 0.5 68 57/38
310 0.4 67 56/37

Dimensions for TR90/90G

Dimensional Drawing TR90/90G

Dimensions for TR130

Dimensional Drawing TR130

Dimensions for TR200

Dimensional Drawing TR200

Dimensions for TR300

Dimensional Drawing TR300

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

Part Description
SPTL Percentage Timer Control
SPBL Push Button Point-of-Use Control
SFM Percentage Timer Control with Furnace Interlock
FT247 Programmable Fan Timer
CAR Metal Backdraft Damper
BD6 6" Gravity Backdraft Damper for TR90(G) thru TR200
BD8 8" Gravity Backdraft Damper for TR90(G) thru TR300
VW106 6" White vinyl wall cap for TR90(G) thru TR200
VB106 6" Brown vinyl wall cap for TR90(G) thru TR200
VT8 8" Taupe vinyl wall cap for TR90(G) thru TR300
FA8-G 8" Galvanized metal wall cap for TR90(G) thru TR300
FA8-P 8" Paintable metal wall cap for TR90(G) thru TR300
VW12x8 12x8" Louver to 8" round galvanized metal wall cap for TR90(G) thru TR300
990076 Universal filters (10 packs of filter media) for TR90(G) thru TR300
990447 Universal filters (3 pack) for TR90(G) thru TR300
